Universal adjustment design

Mounts optical components with 25.4 mm diameter

Used for 30 mm coaxial systems

Suitable for Ø25.4 mm optical components

V-groove and steel balls positioning for easy optical alignment

Compatible with 30 mm coaxial systems

Cylindrical lenses or other rectangular components can be mounted in 30 mm coaxial systems

The sliding arm and coaxial plate can move separately

The 1 mm spaced graduations on the coaxial plate can assist in aligning optical components

Compatible with 30 mm coaxial systems

Clamps round or square components

Adjustable clamping height with locking mechanism

Translate the device along the optical axis of the 30 mm coaxial system

Provide rotation and XY displacement accessories for optical component alignment

Each mounting accessory is sold separately and can be interchanged

Flexure design with travel range scale markings

Precision micrometer actuator, translation with 1 µm graduations

Accommodates 1-inch optics up to 7.2 mm thick

Suitable for Ø25.4 mm optical elements

The inclined groove and base steel ball provide precise six-point positioning, allowing the filter center to align with the coaxial system

The two Ø6 mm coaxial mounting holes on the upper part of the base are blind holes, preventing the coaxial rod from accidentally hitting the filter

X, Y axis travel ±1.5 mm/±2.0 mm, Z axis displacement travel ±1.5 mm

X, Y axis adjustment precision 0.25 mm/revolution, Z axis adjustment precision 0.5 mm/revolution

X, Y threaded pairs with M3 locking screws

X, Y axis displacement range ±1 mm or ±3 mm

X, Y axis adjuster M5 x 0.25, precision 0.25 mm/revolution, X, Y threaded pair with M3 locking screw

Micrometer head drive 10 μm/division

Material: 6061-T6 Aluminum Alloy

Surface Treatment: Black Anodized

Fixed type, adjustable type available

With 3 adjusters, linear movement range ±3 mm

Compatible with Ø25.4 mm optical components

Optical component mounting method: optional retaining ring or set screw

Applicable to anisotropic optical components (such as polarizing optical components)

Comes with 360° rotation and 2° scale accuracy, angle numbers engraved every 20°

Side-mounted with locking screw
